Nocpix QUEST H50R Wärmebildfernglas

Specificaties

Model

Quest H50R

Thermal Sensor

640×512, 12μm

NETD (mK)

≤15

Frame Rate (Hz)

60

Objective Lens (mm)

50 F1.1

Field of View (H×V) (°/m@100m)

8.8×7.0 / 15×12

Magnification (×)

4~32

Detective Range (m) (Target: 1.7m×0.5m, P(n)=99%)

2600

Exit Relief (mm)

25

Exit Pupil Diameter (mm)

10

Diopter (D)

±5

Display Type

AMOLED 1920×1200

Resolution

2560×2560

Battery Type

Built-in & replaceable 18650

Max. Operation Time (h) (t=22℃)

6

Safety Class for Laser

Class 1

Max. Rangefinder Distance (m)

1000

Microphone (MIC)

Support

Memory Capacity (GB)

64

IP Rating

IP67

Operating Temperature (℃)

-20 ~ +50

Weight (g) (with battery)

<700
