Pulsar Proton XQ30 Wärmebild-Vorsatzgerät

Het voorzetapparaat van Pulsar, inclusief het oculair om het apparaat ook te kunnen gebruiken als handkijker! Pulsar Proton XQ30

Exclusief adapter voor de richtkijker.

specs:

Main

Sensor 384×288 pix. @ 17 m

Objective lens F30/1.2

Magnification, x 5

Field of view (HxV), degrees / m@100m 12.4×9.3 / 21.8×16.3

Detection range, m 900

Sensor

Type uncooled

Resolution, pixels 384×288

Pixel pitch, m 17

NETD, mK <40

Frame rate, Hz 50

Optics

Objective lens F30/1.2

Magnification, x 5

Field of view (HxV), degrees / m @ 100 m 12.4×9.3 / 21.8×16.3

Eye relief, mm-

Display

Type AMOLED

Resolution, pixels 1024×768

Range Performance

Detection range, m 900

Laser Rangefinder

Safety class for laser equipment according to IEC 60825-1:2014 –

Wavelength, nm –

Max. measuring range, m –

Measurement accuracy, m –

Video Recorder

Video / photo resolution, pixel 864 648

Video / photo format .mp4 / .jpg

Built-in memory, GB 16

Built-in memory capacity –

Wi-Fi

Wireless Protocol-

Wireless Standard 802,11 b/g

Frequency, GHz 2.4

Bluetooth

Wireless Protocol-

Wireless Standard-

Frequency, GHz-

Environmental Characteristics

Degree of protection, IP code (IEC60529) IP 7

Operating temperature range, -25 +50

Connections and Compatibilities

Mount, type –

Remote control –

Supported Application Stream Vision 1

Power Supply

Output voltage, V 3.0 4.2

Battery type Li-Ion Battery Pack APS5

Capacity, mAh 4900

Operating time on battery pack (at t=22 C), h * 6

External power supply, V 5 (USB Type C)

Weight & Size

Body material Magnesium alloy

Dimensions, mm 248x59x75

Weight, kg –

Trade Data

SKU (Model #) 77378

Status production
